Foundry
Queen's Advanced Micro-Engineering Centre houses a suite of semiconductor processing equipment which are available for customer foundry needs. The equipment set encompasses all sides of silicon processing including:
- Photolithography
- Nanoscribe 3D-SF/3D-MF/3D-LF true 3D printing: nm to mm scale
- Chemical vapour deposition
- Diffusion processes(doping and oxidation)
- Etch(wet chemical etch, RIE, deep ICP etching)
- Metalisation
- Test and Analysis
- Chemical Mechanical Polishing
Follow the Foundry Link for more details of what is on offer.
A copy of the QAMEC Brochure can be found by following the link: publisher pdf
For further information contact the QAMEC manager.
Process Available |
Wafer Size |
|||
75mm |
100mm |
150mm |
200mm |
|
LPCVD Poly silicon |
× |
× |
× |
|
PECVD Oxide/Nitride Deposition |
× |
× |
× |
× |
Layer Analysis: Keyence 6000X 4K digital microscope/White light interferometry/Layer Thickness measurement. |
x |
x |
x |
x |
PVD Metal Deposition |
× |
× |
× |
|
Thermal Processing: Wet and Dry Oxidation. |
× |
× |
× |
|
3D nanoscale printing: Nanoscribe Photonic Professional GT |
3D Polymer Printing from nm to micron scale (Contact for details) |
|||
Chemical Mechanical Polishing (contact for information) |
× |
× |
× |
× |
ALD Al2O3, HfO2 |
× |
× |
× |
|
Optical Lithography >4µm feature size |
× |
× |
× |
|
Photoresist Coat and Develop |
× |
× |
× |
× |
EV Double Sided Aligner |
× |
× |
× |
|
RIE IE of Si3N4,SiO2 |
× |
× |
× |
|
ICP Deep Etch |
× |
× |
× |
× |
Oxide wet Etch |
× |
× |
× |
X |
Poly Wet Etch |
× |
× |
× |
× |
Metal Wet Etch |
× |
× |
× |
× |
Wet Processing |
× |
× |
× |
× |
Surface Treatment |
× |
× |
× |
× |
Evaporation |
× |
|
|
|
Surface and Thin Film Measurement |
x | x | x | x |
Measurement and Test |
x |
Test include CV, IV, Transistor characteristics etc/ Gas chromotography |
